sub-15lb Clyde-Weenie Hongfu FM039...

Who are you (no off-topic talk please)

Moderator: Moderator Team

Post Reply
User avatar
StuTheWeak
Posts: 767
Joined: Sat Apr 09, 2011 11:29 pm
Location: Springdale, AR

by StuTheWeak

First, I'm a clyde (110kgs). I aspire to be a weight weeny, but I also have a few priorities. I need a bike with clinchers due to the poor roads in Arkansas. Also, I can't have parts that are too flimsy due to my weight. So, I'm aiming for a sub-15lb bike that is somewhat robust and easy to work on. The sub-14lb and sub-13lb bikes here are breath-taking, but not practical in my shoes.

To that end I've ordered a number of parts. I'm pulling my hair out trying to save weight on this rig while not sacrificing durability and comfort. Advice is greatly appreciated. Note I'm not attempting any "TUNING" at this time. I'm reserving those actions for phase II. All items are new and purchased through retailers. Prices are rounded to the nearest dollar and include shipping costs.

Stem spacers: 8g -Verified - eBay - Chinese rib flavor carbon - $12
Headset: 12g -Verified - eBay - Alloy 1 1/8" Top Cap, Star Nut, & Bolt - $13
Tires: 417g -Verified - eBay - Serfas Seca 23c & 25c - $70
Groupset & Handlebar MINUS Red brakeset: 1,947g -Verified - eBay - Sram Red GXP - $1534 -Token 44cm carbon - $179
Stem: 134g -Verified - eBay - Ritchey 130mm 73D - $69
Saddle: 169g -Verified - Specialized.com - Specialized Romin Pro 155mm - $160
Tubes: 184g -Verified - Kenda - $4
Tape: 31g -Verified - eBay - Cinelli Cork - $12
Pedals: 180g -Verified - eBay - Exustar titanium & carbon - $265
Skewers: 42g -Verified - eBay - Titanium - $40
Wheelset: 1458g -Verified - Razorback Wheel Company - Velocity Race rear, AC Micro front, IRD Cadence 28/32-(VSR), CX-Ray, alloy-nips, velox - $681
Frameset: 1940g after cutting -Verified - Hongfu - FM039 3K/Glossy finish frameset NON-ISP (56cm), hangers, fork, clamp, seatpost, headset bearings - $660.
Brakeset: 189g -Verified - For Sale Forum - Zero Gravity Ti - $175

Total: 6,711g - $3,874.00

--------------------------------

She's at 14.794lbs on paper from a parts only perspective (without air in the tires). With air in tires, dirt/moisture on/in frame...it's below 14.900lbs.

Someone asked how easy it was to string up the cables using the in-frame cable routing. To tell you the truth it was the easiest wiring job I've ever done. I could do it blind folded. There's actual cable housing molded into the frame. That would explain the extra weight of the frame (1226g). I think a 5yo could wire this bike.

Looking for a tuning kit for my rear mech. Help on that front would be appreciated.
Attachments
Last edited by StuTheWeak on Mon Aug 22, 2011 1:59 pm, edited 205 times in total.
Specialized Allez 06' "Rain Bike" 21.50lbs
Neuvation F100 11' "Road Bike" 16.80lbs
Specialized Tarmac Pro 11' "WW Bike" 14.25lbs

User avatar
kavitator
Posts: 1141
Joined: Sun Sep 21, 2008 9:07 pm
Location: Slovenia---that forest land

by kavitator

Awsome frame! Little remind on Scott Foil

What about some deep V rims?

by Weenie


User avatar
StuTheWeak
Posts: 767
Joined: Sat Apr 09, 2011 11:29 pm
Location: Springdale, AR

by StuTheWeak

She would look sweet as honey with some 50mm tubby carbons. My goal is to stay clincher.

Wish I could get it below 14 pounds, but think that would require a lot more investment. Plus, I want to use solid components that don't require much, if any, maintenance.
Last edited by StuTheWeak on Sat May 07, 2011 11:33 pm, edited 1 time in total.
Specialized Allez 06' "Rain Bike" 21.50lbs
Neuvation F100 11' "Road Bike" 16.80lbs
Specialized Tarmac Pro 11' "WW Bike" 14.25lbs

User avatar
cryoplasm
Posts: 852
Joined: Wed Feb 20, 2008 11:20 pm

by cryoplasm

You could easily drop half the pro peloton with that.

Easily.

User avatar
USofChay
Posts: 425
Joined: Tue May 25, 2010 11:24 pm

by USofChay

Switching to lizardskins tape will save you ~20g.

User avatar
StuTheWeak
Posts: 767
Joined: Sat Apr 09, 2011 11:29 pm
Location: Springdale, AR

by StuTheWeak

Anymore tips/tricks to shave grams off my build???
Specialized Allez 06' "Rain Bike" 21.50lbs
Neuvation F100 11' "Road Bike" 16.80lbs
Specialized Tarmac Pro 11' "WW Bike" 14.25lbs

Johnny Rad
Posts: 1826
Joined: Fri Feb 17, 2006 6:22 am
Location: Zion

by Johnny Rad

Congrats. Hurry up and get it on the road.

The Red crank tests well, but isn't a lightweight. Look at Lightning, Vuma, etc.

Consider swapping SRAM's cables for iLinks, Powercordz, etc.

HillRPete
Posts: 2292
Joined: Tue Apr 12, 2011 8:08 am
Location: Pedal Square

by HillRPete

StuTheWeak wrote:Anymore tips/tricks to shave grams off my build???


Velocity hubs: 78 + 256 = 334g
Soul (Kozak) hubs: 52 + 185 = 237g

There's also a cheaper Soul hub with 59g but you win almost 100g. Didn't check on the price of the Velocity hubs, but the Soul ones are on the more affordable side -- at least in their weight class.

User avatar
StuTheWeak
Posts: 767
Joined: Sat Apr 09, 2011 11:29 pm
Location: Springdale, AR

by StuTheWeak

I weigh 110kgs and using lighter hubs is a stretch. Did order a new wheelset using AC hubs :noidea:

Also, using IRD Cadence rims on the rear is probably a mistake. I'm 100% certain I'll burn through the rear rim in no time. At which time I'll replace it with a Velocity Synergy OC. That's not a typo...Velocity Synergy OC.

The Synergy is a pig (490g), but it's bomb proof (idiot proof in my case). I'll gain 90g, but I'll figure out how to loose weight somewhere else. Could swap out the brakes to shed the 90g...we will see.
Last edited by StuTheWeak on Sat May 14, 2011 8:06 pm, edited 5 times in total.
Specialized Allez 06' "Rain Bike" 21.50lbs
Neuvation F100 11' "Road Bike" 16.80lbs
Specialized Tarmac Pro 11' "WW Bike" 14.25lbs

User avatar
StuTheWeak
Posts: 767
Joined: Sat Apr 09, 2011 11:29 pm
Location: Springdale, AR

by StuTheWeak

The seat and stem arrived.

Seat is 155mm wide and less than 159g. That's using a Fedex scale which probably isn't accurate. Though it looks nice and comfy :)

The stem has a shiney front cap...which I don't like. You would have thought I'd have noticed that from the start. Though for me to fit a 56cm frame I need a LONG stem and a fair amount of drop (-17)...that's how we roll 8)

Trying to stick with Serfas SecaRS tires...they aren't sexy, but they work really well. That's speaking of the NEW SecaRS (post-2009 model). The old model sucked big time (pre-2010).

The new Seca-RS tires are brilliant. I could argue they are road tires disguised as training tires. They are smartly designed with thick casing...then small groves cut into the sides to appear to create tread, but really it just reduces the weight of the tire as a whole. So, you have a tire with thick tread, but light weight. They should be given an award for "smartest tire".

More to come...
Attachments
Last edited by StuTheWeak on Sat May 14, 2011 8:10 pm, edited 2 times in total.
Specialized Allez 06' "Rain Bike" 21.50lbs
Neuvation F100 11' "Road Bike" 16.80lbs
Specialized Tarmac Pro 11' "WW Bike" 14.25lbs

Impulsive1
Posts: 62
Joined: Fri Mar 13, 2009 2:39 am

by Impulsive1

StuTheWeak wrote:I'm relatively new here. Got ahold of Jane at Hongfu and placed an order for a FM039...my build sheet is coming together nicely. Will post pics once I've got something to show.


BLACK UD finish frame (56cm), fork, seatpost, headset 1800g $660 -ORDERED
BLACK Sram Red GXP groupset 2214g $1649 - ORDERED
BLACK Token 44cm carbon bars 185g $179 - ORDERED
BLACK Ritchey WCS Stem BB, 130mm 73D 130g $69 - ARRIVED
BLACK Specialized Romin Pro <159g $160 - ARRIVED
BLACK Pair Serfas Seca 430g $75 - NOT ORDERED
BLACK Wal-Mart Tubes 200g $6 - NOT ORDERED
BLACK Cork tape 56g $12 - ORDERED
BLACK E-PR200CKTi pedals 176g $265 - ORDERED
BLACK Velocity Race hubs (offset flange), IRD NIOBIUM 28h/32h-(VSR), CX-Ray 1422g $615 - ORDERED
BLACK Ti Skewers 44g $37 - ORDERED
_________________________________
Total: 6,816g $3,733.00

She's at 14.9952lbs on paper :?

Granted I'm guessing on the "high" side for all the components, but I don't want to build it up and be extremely disappointed. Have faith in God, but keep your sandpaper handy!

I could go Conti Super Prix with tires/tubes, but I want to keep it real. I weigh 110kgs...I really want reliable/comfortable tires/tubes, wheels and seat.


I like it. Looks similar to my Giant Tcr Advanced especially the seatpost, seatstays, chainstays.

User avatar
StuTheWeak
Posts: 767
Joined: Sat Apr 09, 2011 11:29 pm
Location: Springdale, AR

by StuTheWeak

That's a sweet ride :)

You put her on the scales?

Speaking of scales..I've order a digital scale so I can better record my progress. Also, I'm going to order a digi cam so i can take pics.
Specialized Allez 06' "Rain Bike" 21.50lbs
Neuvation F100 11' "Road Bike" 16.80lbs
Specialized Tarmac Pro 11' "WW Bike" 14.25lbs

User avatar
StuTheWeak
Posts: 767
Joined: Sat Apr 09, 2011 11:29 pm
Location: Springdale, AR

by StuTheWeak

Here are some pics to keep you people warm at night...
Attachments
This is the beast...foul weather critter.
This is my kicka$$ F100...except for the bent aluminum axle...she rocks my world.
This is my new bike...how you like?
Specialized Allez 06' "Rain Bike" 21.50lbs
Neuvation F100 11' "Road Bike" 16.80lbs
Specialized Tarmac Pro 11' "WW Bike" 14.25lbs

User avatar
jamesfifield
Posts: 32
Joined: Tue May 10, 2011 2:02 pm

by jamesfifield

I take it the pictures are to show the build kit that will go on the new frame?
I'm very interested in the frameset, please post a report (with pictures of course) when it's ready!

by Weenie


User avatar
StuTheWeak
Posts: 767
Joined: Sat Apr 09, 2011 11:29 pm
Location: Springdale, AR

by StuTheWeak

jamesfifield wrote:I take it the pictures are to show the build kit that will go on the new frame?
I'm very interested in the frameset, please post a report (with pictures of course) when it's ready!


Yes, delivery on items has been very slow. I suspect the flooding in and around Memphis isn't helping matters (Fedex distribution center).

Sorry for the grainy photos, but it's the only digi I have.
Specialized Allez 06' "Rain Bike" 21.50lbs
Neuvation F100 11' "Road Bike" 16.80lbs
Specialized Tarmac Pro 11' "WW Bike" 14.25lbs
